The ECHO is the evolution and direct replacement for our beloved ALLROAD platform.  It’s the perfect bike for those seeking the quiver killer for fast road riding to gravel.   The ECHO takes the versatility  of the ALLROAD and expands the tire clearance up to 40mm and allows a truly optimized road geometry thanks to it’s flip-chip system.

Sample Build Options - (Any build can be customized or let us design your dream bike)

Dura-Ace R9200 Di2

Shimano Dura-Ace R9200 Di2 Build Kit, Industry Nine i9.35 Carbon Wheelset, Black Inc Carbon Road Handlebar & Seatpost.

As usual, build it any way you like and pick your color.


Force AXS

SRAM Force AXS 2x12 Build Kit, Industry Nine UL250 CX 700 Wheelset, FSA K-Force Compact Carbon Handlebar

As usual, build it any way you like and pick your color.


Rival AXS

SRAM Rival AXS 2x12 Build Kit, Industry Nine 1/1 GRCX 700 Wheelset, FSA Energy Compact Handlebar

As usual, build it any way you like and pick your color.


Meet the Echo

At the heart of the ECHO’s genetic code is pure unadulterated speed - the ability to transform from a road race thoroughbred to a versatile, agile gravel bike with a simple switch of flip chips at the front and rear dropouts. These eccentric chips and corresponding dropout design allow the rider to easily change the bike geometry, effectively changing the chainstay length and fork length by 1 cm. The difference transforms the bike from a road machine with 415mm chainstay length, 368mm fork length, 73-degree headtube angle, and tire clearance for up to 30mm, to a gravel bike with 425mm chainstay length, 378mm fork length, 72.5mm headtube angle, and 40mm tire clearance - all within a 10-minute switch of dropout chips. Pure road performance one day, gravel race-ready the next. One bike. No compromise.

The ECHO Stem is a fully integrated system designed in tandem with the fork. It conceals the cables while using a standard headset allowing the rider to easily swap stem lengths, and it works with a growing list of handlebars designed with integrated cables in mind. The ECHO stem system is the simplest and most user-friendly on the market today. The cables run through a channel on the top of the stem and are concealed by a faceplate, top cap, and the steerer tube. Headset adjustment is moved from the traditional position at the top of the stem to a threaded portion on the bottom of the stem, effectively increasing the steerer clamp length to provide headset preload, much like a threaded headset. The Echo stem is available in 6 sizes at 10mm increments (80-130mm) and is a -6 degree drop. Like all things designed by Allied, the ECHO stem is made in our Bentonville factory.


Flip Chips change geometry between road and gravel.
ECHO Stem hides the brake cables, provides incredible stiffness and is painted to match.
The ECHO is compatible with all current electric road and gravel 1x and 2x drivetrain options from Shimano and SRAM.
2x downtube,  and 1x seat tube
700x30mm in road mode, and 700x40mm, or 650x2.0" in gravel mode.
